IEC Standards Catalog - Iec Standard 80 - 6 Poles - Ø 125 x 80

IEC stands for International Elctrotechnical Commision, founded in 1906 with the purpose of establishing and implementing international standards to electric technologies and their components. International Electrotechnical Commision, (Commission electrotechnique internationale), is an international association that defines the standards for electricity, electronics and their products.

stator

DE mm toll. External diameter of stator
125
DI mm toll. Internal diameter of stator
80
COD Code
446
NS n. Number of stator slots
36
AS mm toll. Area of stator slots
57
K mmq Rad. width of stator circuit ring
9.5
S mm Width of stator tooth
3.4
PS gr/mm Weight stator lamin.th.0,5 mm
19.70
E Entry size of stator slots
2.30

rotor

DE mm toll. External rotor diameter
80
NR n. Number of rotor slots
30
AR mmq Area of rotor slots
28.6
PR gr/mm Weight of rotor lam.th. 0,5 mm
14.7
